Standard Master User Functions | IDS X Series Training V2.3
Option 11 - User Partition Allocation
By default each user is allocated to partition one. If more partitions exist then users must be allocated to
the correct partition or multiple partitions.
Example:
Option 13 - User Outputs
Note: The user code property “Programmable Output Code” must be enabled before this option
will work
This is to allocate the output which the user code set as an output trigger code, in option 10, must
activate.
Example
Instruction
Key presses
Press and hold the [*] key for 3 seconds
[*]
Enter the master code, followed by the [*] key
[1][2][3][4] [*]
Enter the value to call up the user code output allocation, followed by the [*] key
[1][3] [*]
Now enter the user code, followed by the [*] key
[2][3][6][5] [*]
Allocate the output, followed by the [*] key
[5] [*]
Allocate the action, followed by the [*] key
[2] [*]
When complete press the [#] key
[#]
This will leave you in the master menu
Below is a table of the available outputs and their corresponding values:
Note: By default there are only five outputs on the alarm panel. The other outputs are only
available if the device that has the output required is installed.
Address
Physical Outputs
Address
Physical Outputs
00
Disabled
13
Zone expander 4 output 2
01
Onboard output 1
14
Zone expander 5 output 1
02
Onboard output 2
15
Zone expander 5 output 2
03
Onboard output 3
16
Zone expander 6 output 1
04
Onboard output 4
17
Zone expander 6 output 2
05
Onboard output 5
34
Keypad 1 output
06
Zone expander 1 output 1
35
Keypad 2 output
07
Zone expander 1 output 2
36
Keypad 3 output
08
Zone expander 2 output 1
37
Keypad 4 output
09
Zone expander 2 output 2
38
Keypad 5 output
10
Zone expander 3 output 1
39
Keypad 6 output
11
Zone expander 3 output 2
40
Keypad 7 output
12
Zone expander 4 output 1
41
Keypad 8 output
The actions that can be performed by the outputs are:
Instruction
Key presses
Press and hold the [*] key for 3 seconds
[*]
Enter the master code, followed by the [*] key
[1][2][3][4] [*]
Enter the value to call up the user codes partition information, followed by the [*] key
[1][1] [*]
Now enter the user code, followed by the [*] key
[2][5][8][0] [*]
Allocate the partitions to the user code, followed by the [*] key
[2] [*] [3] [*] [5] [*]
When complete press the [#] key
[#]
This will leave you in the master menu
Value
Output Action
Description
0
Set Output High (Set)
Set high or latch: The output‟s voltage will be set to 12V
1
Set Output Low (Reset)
Set low or unlatch: The output will be reset back to 0V
2
Pulse Output High
The output will be set to 12V for 3 seconds then reset back to 0V
3
Pulse Output Low
Used when the output is already at 12V. This will reset the output to 0V
and restore it to 12V after 3 seconds
