Reporting Codes
In the following locations the value of the reporting codes are entered for reporting formats other than SIA and Contact ID.
For example formats like, FBI 4x2.
[INSTALLER CODE] [*] [LOCATION] [*] [SUB-LOCATION] [*] [REPORTING CODE] [*]
Note: Please take note of the changes to some of the reporting locations to accommodate the new wireless.
New wireless additions are highlight in bold text
Location 300 Global Reporting
Sub Loc
Description
Explanation
1
AC Fail
Enter the code that is to be reported when the main electrical
supply has failed and the system is running on the backup battery
2
AC Restore
This reporting code is sent when the main electrical supply is
restored
3
Communication Fail
The X64 can be programmed to try and communicate a number of
times via the phone line. When these attempts have been
exhausted a communication fail is sent.
4
Communication Restored
When communication is restored the code is sent
5
Phone line tamper
If the phone line is tampered with and the line voltage goes
missing an alert is sent
6
Phone line restore
When the line voltage is restored a reporting code is sent alerting
the security company
7
Siren tamper
The X64 monitors the siren and if it goes missing a signal is sent
8
Siren tamper restore
Once the siren has been restore the security company is alerted
Location 301 Global reporting
Sub Loc
Description
Explanation
1
Battery Low
After AC has failed and the system detects that the battery voltage
has reached 10.5V this code is sent to warn the company that it is
about to switch off because of the lack of power
2
Battery Restore
Once charged a restore will be sent to confirm the battery is
charged
3
Auxiliary 12V Fuse failed
If the fuse protecting the auxiliary 12V output latches off a code
can be sent to alert the security company
4
Auxiliary 12V Fuse restored
When the fault is corrected a restore is sent
5
Installer reset required
If this option is enabled in location 211 to 218 and the alarm is
tripped in the partition that it is enabled in, the alarm cannot be
armed until the installer code is entered.
6
Installer reset restored
Once the installer code has been entered after an alarm has
tripped a restoral will be sent
7
Box tamper
On the alarm panel is a connector that a switch can be connected
to monitor the box that it is in so it cannot be opened without
notifying the security company
8
Box tamper restore
When the box is closed a restore is sent
