Event Reporting
When using contact ID and SIA formats all event codes are programmed into the X64 and only need to be
enabled or disabled in the following locations. Also the split reporting group can be allocated.
Location 501 to 564 Global Split Reporting
These locations are for each of the zones, 501 is for zone 1, 502 is for zone 2, 503 is for zone 3, etc.
LED
ON/OFF
Action
Explanation
Split Reporting
Option
1
ON
Zone alarm reporting
If this option is selected whenever a zone is violated
the alarm reports via telephone
9 OFF
2
OFF
Zone alarm restore
When the zone restores the alarm reports via
telephone
10 OFF
3
OFF
Zone bypassing
When a zone is bypassed it is reported via telephone
11 OFF
4
OFF
Zone force bypassing
When the system is set to bypass zones that are
violated when arming it reports that it was forced to
arm by bypassing zones
12 OFF
5
OFF
Zone tamper
When tamper has been set for a zone and the
tamper signal is received it will be reported via
telephone
13 OFF
6
OFF
Zone tamper restore
When the tamper restores a report is sent via
telephone
14 OFF
7
OFF
Zone swinger
shutdown
A zone shuts down because it has exceeded the
shutdown count and the system will report via
telephone
15 OFF
8
OFF
Zone swinger
shutdown restore
At the auto test report, the system will try and restore
the zone if it is not violated and this will be reported
via telephone
16 OFF
Options 9 to 16 are to select which split reporting telephone numbers to report too.
Off = split reporting group 1, On = split reporting group 2
Location 571 Global Split Reporting
Options 9 to 16 are to select which split reporting telephone numbers to report too.
Off = split reporting group 1, On = split reporting group 2
LED
On/Off
Action
Explanation
Split Reporting
Option
1
ON
AC fail reporting
After the wait time set in loc.?? The AC failure will be
reported
9 OFF
2
OFF
Communication fail
reporting
If the system cannot report a failure to report message
is sent
10 OFF
3
ON
Telephone line tamper
reporting
The alarm monitors the voltage on the telephone line
and if that it goes missing a tamper is reported
11 OFF
4
ON
Siren fail reporting
The siren output monitors the load on the output and if
it goes missing then a tamper is reported
12 OFF
5
ON
Panel low battery fail
reporting
When AC is off and the battery voltage drops to 10.5V
a battery low signal is sent, warning that the system is
close to shutting down
13 OFF
6
ON
Enable aux 12V fuse fail
reporting
If a short circuit or too much current is drawn from the
auxiliary 12V the fuse will shut off and send a signal
warning of a problem
14 OFF
7
OFF
Installer Reset Required
If installer reset is enabled in loc.211 to 218 and the
alarm is triggered the system will not arm until the
installer code is entered. This alerts the security
company of this
15 ON
8
ON
Box tamper reporting
The alarm has an input that monitors a switch that
monitors if the housing that it is in is opened
16 OFF
