I/O time setup
8
p.29
Output Port Setting Table
You must specify the port settings using whatever combination of the followings if you
want the device to operate in Secure mode or normal + Secure mode.
Port Setting Value Example
Operation mode setting value EX 1)
If only the door relay operates in normal and
Secure modes
Normal and Secure modes: 50
Door Relay: +01
Output Port Setting Value: 51
EX 2)
If the alarm relay and the TTL output operate in
Secure mode
Secure Mode: 00
Alarm Relay, TTL: +06
Output Port Setting Value: 06
Operate only in Secure mode 00
Operate in normal mode and
Secure mode
50
Operation port setting value
Operate the door relay only 01
Operate the alarm relay only 02
Operate the TTL output only 04
Operate the door relay and TTL
output
05
Operate the alarm relay and TTL
output
06
