Advanced setting
100RV
p.39
7 To specify the input mode for the exit button
You can specify an operation for the Exit button when it switches from LOW (0V) to HIGH
(5V).
1. Present the Master Card to the device.
2. Press Button and Button in sequence and press .
• To release the setting, press the < > buttons and press .
The default is set to “switch from HIGH(5V) to LOW(0V)”.
8 To specify the input mode for the door contact sensor
You can specify an operation for the Door Contact Sensor when it switches from LOW (0V)
to HIGH (5V).
1. Present the Master Card to the device.
2. Press Button and Button in sequence and press .
• To release the setting, repeat Step 1 above, select the < > buttons and press
.
The default is set to “switch from HIGH(5V) to LOW(0V)”.
