IDTECK 100RV - To Specify the Alarm Operation Time for AUX 1

p.32
I/O time setup
100RV
2. Press Button and Button in sequence and press .
3. Refer to the output port table on page 28 and specify a desired output mode.
• If you want the alarm relay alone to operate in normal and Secure modes in case of
an error from the Door contact Sensor, select the < > buttons and press .
4. Enter the two-digit door relay output time and press .
5. Enter the two-digit alarm relay output time and press .
6. Enter the two-digit TTL relay output time and press .
• You can specify a two-digit time from 00 to 99 seconds.
• By default, all output times are set to “00”.
Other output ports that are not specifi ed for the output mode will not be
activated.
For instance, if you set the output mode to [5][2] and assign the operation time
for each output device by following the steps 4, 5, and 6 above, only the alarm
relay will operate.
5 To specify the alarm operation time for AUX 1
1. Present the Master Card to the device.
2. Press Button and Button in sequence and press .
3. Refer to the output port table on page 28 and specify a desired output mode.
• If you want the alarm relay alone to operate in normal and Secure modes in case of
an input through the auxiliary port, select the < > buttons and press .
4. Enter the two-digit door relay output time and press .
5. Enter the two-digit alarm relay output time and press .
6. Enter the two-digit TTL relay output time and press .
• You can specify a two-digit time from 00 to 99 seconds.
• By default, all output times are set to “00”.
