Other information
100RV
p.45
15. Control Lock by the Door Sensor : Disabled
2 Function codes
No. Code number Function item
1 11 Additional user card registration (RF CARD ONLY MODE)
2 12 Additional user card and PIN registration (RF CARD + PIN MODE)
3 13 Additional PIN registration (PIN ONLY MODE)
4 14 Delete a registered card or PIN number
5 15 Additional user card or PIN registration (RF/PIN combination
mode)
6 21 To specify the output time if the card is authenticated
7 22 To specify the output time if the card is not authenticated
8 24 Set the Door Contact Sensor alarming time
9 25 Set the AUX 1 alarming time
10 26 Set the AUX 2 alarming time
11 27 Set the AUX 3 alarming time
12 29 Set the Duress Mode password (2 digits)
13 30 Set the TTL output time in Duress Mode
14 31 To check the output of the registered card user (test on code 21)
15 32 To check the output of the unregistered card user
16 34 To check the output specififi ed for the Door Contact Sensor alarm
17 35 To check the output specififi ed for AUX 1
18 36 To check the output specififi ed for AUX 2
19 37 To check the output specififi ed for AUX 3
20 39 Set the chime bell ringing time
21 41 Set the door open
22 42 Release the door opening
23 43 Set the QUICK Mode
24 44 Release the QUICK Mode
25 45 Toggle to control the door relay
26 46 Release the toggling to control the door relay
27 47 Set to control the door relay using the Door Contact Sensor
28 48 Release the control of the door relay using the Door Contact
