IFM Electronic PY995 Series User Manual

• The pressure sensor detects the system pressure,
• shows the current system pressure on its display,
• and generates 2 output signals according to the set output
configuration.
Applications (Type of pressure: relative pressure)
Avoid static and dynamic overpressure exceeding the given over-
load pressure.
For gaseous media the application is limited to max. 25bar.
Even if the bursting pressure is exceeded only for a short time
the unit can be destroyed (danger of injuries)!
17
ENGLISH
Function and features
Output 1
hysteresis function / N.O. (Hno)
hysteresis function / N.C. (Hnc)
window function / N.O. (Fno)
window function / N.C. (Fnc)
Output 2
analogue 4 ... 20 mA (I)
analogue 0 ... 10 V (U)
Bursting
pressure
Permissible
overl. pressure
Measuring rangeOrder no.
bar bar bar
PY9951
0...250 400 850
PY9954
-1...10 75 150
PSI
0...3625
- 14,5...145
PSI
5800
1087
PSI
12300
2175
*Span of the analogue signal for PY9954: 0...10bar / 0...145PSI
MPa = bar ÷ 10 / kPa = bar × 100
