12.1 Setting ranges
FLOW
SP1 / SP2 rP1 / rP2 ASP AEP
∆Q
min max min max min max min max
Nl/min 30 3750 12 3732 0 2813 937 3750 1
Nm
3
/h 1�8 225�0 0�7 223�9 0�0 168�8 56�2 225�0 0�1
Nm/s 0�9 109�2 0�4 108�7 0�0 81�9 27�3 109�2 0�1
TEMP
SP2 rP2 ASP AEP
∆T
min max min max min max min max
°C 0�4 60�0 0�2 59�8 0�0 45�0 15�0 60�0 0�2
ImPS
min max
0�003 Nm
3
3,000,000 Nm
3
(∆Q,∆T=stepincrement)
