IFM E30391 - Display Configuration; QR Code

13
3.7. Display configuration
Definition of rotation, brightness and colour scheme of the display.
Name
Index /
subindex
Type /
length
Content
diS.R 801/0
UINT8/1
Rotation of the display
Setting values: 0°, 90°, 180°, 270°
diS.B 802/0
Brightness of the display:
0 %, 25 %, 50 %, 75 %, 100 %
diS.S 803/0 Colour scheme of the
display: 0 = black
background 1 = white
background
3.8. QR code
To display the content defined in this index as QR code on the
screen set the layout type of the display to [QR-Code] → 4.1
Name
Index /
subindex
Type /
length
Content
QR code 830/0 String/122 URL or short free text
