IFM E30391 - Process Value Display; Text Content for Info Pages

7
3.2. Process value display
Name Index /
subinde x
Type /
length
Content
Unit 1 80/0
String/8
Units of the process
values
Unit 2 81/0
Unit 3 82/0
Unit 4 83/0
Description 1 90/0
String/16
Description text of
the process values
Description 2 91/0
Description 3 92/0
Description 4 93/0
Decimal place 1 100/0
UINT8/1
Number of decimal places of
the process values:
0 = no decimal place
1 = 1 decimal place
2 = 2 decimal places
3 = 3 decimal places
Decimal place 2 101/0
Decimal place 3 102/0
Decimal place 4 103/0
3.3. Text content for info pages
Up to 16 characters per line can be used.
Name Index /
subind ex
Type /
length
Content
Info page 1, line 1 120/0
String/16 Text content of page 1
Info page 1, line 2 121/0
Info page 1, line 3 122/0
Info page 1, line 4 123/0
Info page 1, line 5 124/0
Info page 2, line 1 125/0
String/16 Text content of page 2
Info page 2, line 2 126/0
Info page 2, line 3 127/0
Info page 2, line 4 128/0
Info page 2, line 5 129/0
