Name Byte
offset
Type /
length
Note /
content
Color1: Display
line 1
8.0
INT8/1
Colour and flashing (frequency 2 Hz)
Colour of the static
process value:
0 = black-white
1 = red
2 = green
3 = yellow
Colour of the static display text:
80 = text black and white
81 = text red
82 = text green
83 = text
yellow
Colour of the flashing
process value:
40 = black-white
41 = red
42 = green
43 = yellow
Colour of the flashing
display text:
120 = text black and white
121 = text red
122 = text green
123 = text
yellow
Color2: Display
line 2
9.0
Color3: Display
line 3
10.0
Color1: Display
line 4
11.0
LEDs 12.0 Bool
/ 1
bit
0 = LED I off
1 = LED I yellow
12.1 Bool
/ 1
bit
reserved
12.2 Bool
/ 1
bit
0 = LED II off
1 = LED II yellow
12.3...12.7 reserved
