5.2.3 Quick setup: Configure the output access
17867
Only one control instance at a time can have write access to the outputs of the connected AS-i slaves.
The operator configures the control instance with the parameter [Output access].
To configure the control instance of the AS-i slave outputs:
1 Select the menu page
►
► Select [Operation modes] tab.
2 Set the control instance for the outputs of the AS-i slaves
► From the list [Output access], select the desired value:
Parameter
Meaning
Possible values
[Output access]
Control instance of the AS-i
slave outputs
Gateway =
A higher-level PLC controls the outputs of
the AS-i slaves.
Manual =
The operator controls the outputs of the
AS-i slaves via the graphical user interface.
PLC =
The device-internal PLC controls the
outputs of the AS-i slaves.
3 Save the changes
► Press [Accept selection] to save the changes.
> The selected instance controls the outputs of the AS-i slaves.
>
5.2.4 Quick setup: Access the device via QR code
11764
The QR code (Quick Response Code) allows the operator to access the web interface of the device
from a smartphone or tablet PC.
Requirements:
 The AS-i device must be connected to a wireless LAN router with switch functionality.
(→ Connection via Ethernet network (→ page 135))
 The smartphone/tablet PC is connected to the wireless LAN router.
 The smartphone/tablet PC provides a camera function.
 The smartphone/tablet PC has a QR-code reader installed.
1 Select menu page
►
► Select the [QR-Code] tab.
> The display shows the QR code.
2 Read the QR code
► Start the QR code reading app and scan the QR code.
> The smartphone displays the web interface of the device (→ Remote access (→ page 39)).
