ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Menu Quick setup
– [Subnet mask]
– [Gateway address]
► Press [Accept] to save the changes.
► Continue with → step 5
4 Configure the IP parameters automatically
► Check [Optain IP address autom.].
► Press [Accept] to save the changes.
> The device tries to obtain IP parameters from a DHCP server.
> If the IP parameter configuration via DHCP server fails, the device will generate the IP parameters by means of the
Zeroconf protocol.
The automatic configuration of the interface takes approx. 10 seconds.
5 Show the current settings
> The parameters (→ step 2) show the active IP settings of the configuration interface.
