Menu AS-i 1 / AS-i 2
>
Change the digital output values manually
10939
WARNING
Risk of personal injury! Risk of material damage to the machine/plant!
The operator is responsible for any consequences caused by the manual change of the digital ouput
values!
► Secure the concerned area.
► Only trained personnel is allowed to set outputs manually.
If the jog mode is deactivated:
After changing the slave outputs the output values remain on the changed values.
► Change the inverted outputs again immediately to the original values after the end of the test!
To change the digital output values of an AS-i slave manually:
1 Enable manual access to the outputs
► Set parameter [Output access] = Manual (→ Set the output access (→ page 75)).
2 Select the menu page
► > or >
► Select an AS-i slave (→ Slave selector (→ page 30)).
► Select [Data] tab.
3 Set the digital output values manually
> The group [Outputs] displays the current value of the digital output (binary and hexadecimal representation).
► [Jog mode] to be set as required. (→ Digital output (→ page 62))
► Change the desired output value bit by bit.
> Selected value is applied.
>
Change the analogue output values manually
10940
To change the analogue output values of an AS-i slave manually:
1 Enable manual access to the outputs
► Parameter [Output access] = set to Manual (→ Set the output access (→ page 75)).
2 Select the menu page
► > or >
► Select an AS-i slave (→ Slave selector (→ page 30)).
► Select [Data] tab.
3 Set the analogue output values manually
> [Outputs] group shows the current value of the analogue output.
► Change the value of the requested channel one digit at a time (→ Numerical field (→ page 36)).
> Selected value is applied.
► Optional: repeat step 3 to change further channels.
