ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Menu AS-i 1 / AS-i 2
>
Show AS-i slave information
10935
To display information about an AS-i slave:
1 Select the menu page
► > or >
► Select an AS-i slave (→ Slave selector (→ page 30)).
► Select [Information] tab.
2 Display information about the AS-i slave
> Page shows the following information:
Designation
Meaning
Possible values
[AS-i Slave address]
Current address of the AS-i slave
e.g. 13B
[Slave status]
Current status of the AS-i slave
=
AS-i slave is active
=
AS-i slave is missing
=
Not projected
=
Double address error
=
Periphery fault
[AS-i slave profile]
Current (= Current) and expected
(= Preset) slave profile (IO, ID, ID2,
ID1) in hexadecimal format
► Use [] / [] for page navigation.
