ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Menu AS-i 1 / AS-i 2
>
Change an AS-i slave address
10944
To change the address of an AS-i slave:
1 Select the menu page
► > or >
► Select an AS-i slave (→ Slave selector (→ page 30)).
► Select [Setup] tab.
2 Change the address of the AS-i slave
► Press the [Change slave address] button.
> The page displays an overview of the free AS-i addresses (→ Overview of free slave addresses (→ page 33)).
► Select the address to be assigned to the AS-i slave and confirm with [Select] function key.
> Security prompt appears.
► Press [OK] to confirm the security prompt.
> The AS-i slave has a new address.
> The page displays an overview of the AS-i slave states (→ Overview of slave states (→ page 31)).
3 Optional: change further AS-i addresses.
► Repeat step 2 to change further AS-i slave addresses.
After the address change, the present configuration (LDS) no longer corresponds to the
stored configuration (LPS).
> The OSC displays a configuration error.
To remove the configuration error:
► start a projection adaptation (→ Carry out a projection adaptation (→ page 58)).
>
Change an AS-i slave parameter output
10945
To change the parameter output of an AS-i slave:
1 Enable manual access to the outputs
► Set [Output access] = Manual (→ Set the output access (→ page 75))
2 Select the menu page
► > or >
► Select an AS-i slave (→ Slave selector (→ page 30)).
► Select [Setup] tab.
3 Change the parameter output of the AS-i slave
> The group [Parameter output] displays the current assignment of the parameter output (binary and hexadecimal
representation).
► Adjust the desired output value one position at a time.
> Selected value is applied.
