Menu System
>
Control PLC applications
14847
To control all PLC applications stored on the device:
1 Select the menu page
► > >
► Select [All applications] tab.
2 Display status information about the PLC applications
> Page shows the following information:
Designation
Meaning
[Total]
Number of applications stored on the device
[Started]
Number of applications running
► Perform one of the following actions:
– Launch all PLC applications: continue with → step 3
– Stop all PLC applications: continue with → step 4
– Reset all PLC applications: continue with → step 5
3 Launch all PLC applications
► Press [Start] button.
> The confirmation prompt appears.
► Press [OK] to confirm the prompt.
> All PLC applications are started.
► Continue with → step 6
4 Stop all PLC applications
► Press [Stop] button.
> The confirmation prompt appears
► Press [OK] to confirm the prompt.
> All PLC applications are stopped.
► Continue with → step 6
5 Reset all PLC applications
► Press [Reset] button.
> The confirmation prompt appears.
► Press [OK] to confirm the prompt.
> All PLC applications are reset and stopped.
6 Display the status of the PLC applications
> The page shows updated information about the stored PLC applications.
> The status of the [Start], [Stop] and [Reset] buttons is updated.
