ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Menu System
>
Show target visualisation
9055
Using the CODESYS programming system, the user can optionally program a target visualisation to
create an application-specific user interface for the display of AC142n. The target visualisation is
loaded onto the device together with the CODESYS project, but it must be activated manually.
If no valid target visualisation is stored on the device, a green screen appears after activating
the [Activate Target-Visu] button
To exit the target visualisation and return to the menu page:
► Press [] and [] simultaneously.
If the device does not react when entering [] + [], the key combination is deactivated.
► Activate the key combination using the system command "Show target visualisation"
(→ Command 272 (0x0110) – Display target visualisation (→ page 267))!
To activate the target visualisation:
1 Select menu page
► > >
► Select the [Activate TargetVisu] tab.
2 Start the target visualisation
► Press [Activate Target-Visu] button.
> The confirmation message appears.
► Press [OK] button to confirm the message.
> The display shows the target visualisation.
