ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Menu Interfaces
>
Download the device and I/O description
12194
This function is only available via the web-interface of the device (→ Remote access
(→ page 39)).
Requirements:
► Connect the device with PC/laptop (→ Configuration interface: connection concepts (→ page 133)).
► Start the web browser and open the web interface of the device (→ Recommended browsers (→ page 40)).
1 Select the menu page
► > >
► Select [File download] tab.
> The menu screen [File download] appears.
2 Download the EDS file and the description of the inputs and outputs.
► Click the link [Download EDS-Datei] to download the device description.
► Click the button [Download I/O Description file].
> The web server creates a description file of the inputs and outputs.
► Save the created file.
