ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Menu Interfaces
>
EtherNet/IP: Setup
16196
The [Setup] menu item provides access to the configuration options of the EtherNet/IP interface.
>
Notes on IP settings
12228
The device provides the following options for configuration of the EtherNet/IP interface:
 Manual =
The operator sets the interface parameters (IP address, network mask,
gateway address) manually.
 Automatic =
The interface parameters are automatically set through one of the
following protocols.
– Dynamic Host Configuration Protocol (DHCP)
– Bootstrap Protocol (BOOTP)
To display the current configuration method for IP parameters of the EtherNet/IP interface:
1 Select the menu page
► > >
► Select [Fieldbus] tab.
2 Display the current configuration method for IP parameters
> The [IP mode] list shows the active configuration method:
- Static =
The operator sets the IP parameters manually.
- DHCP =
The device receives the IP parameters from a DHCP
server.
- BOOTP =
The device receives the IP parameters from a BOOTP
server.
3 Display the current IP parameters of the EtherNet/IP interface
> The following parameters show the current IP settings of the EtherNet/IP interface:
Designation
Meaning
[IP address]
IP address of the configuration interface
[Subnet mask]
Subnet mask of the network segment
[Gateway address]
IP address of the EtherNet gateway
