Configure the IP parameters manually
15883
To manually configure the IP parameters of the EtherNet/IP interface:
1 Select the menu page
► > >
► Select [Fieldbus] tab.
2 Activate the manual configuration
► From the list [IP mode], select the value Static (→ Notes on IP settings (→ page 96)).
> The IP address fields [IP address], [Subnet mask] and [Gateway address] can be edited.
3 Set the IP parameters of the EtherNet/IP interface
► Set the following parameters as required:
– [IP address]
– [Subnet mask]
– [Gateway address]
4 Save the changes
► Press [Accept] button.
> Selected values are applied.
>
Configure the IP parameters automatically
15881
In order to obtain the interface parameters automatically via DHCP or BOOTP, the device
must be connected to a DHCP or BOOTP server.
► Connect the EtherNet/IP interfaces (X6/X7) to a DHCP/BOOTP server.
1 Select the menu page
► > >
► Select [Fieldbus] tab.
2 Select the configuration method
► From the list [IP mode], select either DHCP or BOOTP.
3 Save the changes
► Press [Accept] button.
> The device receives the IP parameters from a DHCP or BOOTP server.
> Selected value is applied.
> [IP address], [Subnet mask] and [Gateway address] show the current values.
