ifm Device Manual SmartSPS AC14 with EtherNet/IP interface (AC1421, AC1422), Firmware 3.1.2 2015-11-30
Menu Interfaces
>
Set the configuration mode
15884
More information: → Configuration mode (→ page 335)
To set the configuration mode of the device:
1 Select the menu page
► > >
► Select [Fieldbus] tab.
2 Select the configuration method for the EtherNet/IP parameters
> Set the following parameter as required:
Parameter
Meaning
Possible values
[configuration mode]
Active configuration mode of
the device
Top-Down =
The device-specific parameters and the
module configuration are set via the
projection software of the EtherNet/IP
controller.
Independent =
The parameters of the EtherNet/IP
interface are set via the graphical user
interface of the device.
3 Save the changes
► Press [Accept].
> Selected value is applied.
