Set the device-specific parameters
15909
The parameters can only be changed if the configuration mode is set to Independent (→ Set
the configuration mode (→ page 98)).
To set the device-specific parameters: set the number of channels to be transmitted per analogue
input slave:
1 Select the menu page
► > >
► Select [Parameter] tab.
2 Set the number of analogue channels per input slave
► Set the following parameter as required:
Parameter
Meaning
Possible values
[Analog. channels/I-slave]
Number of analogue
channels transmitted per
input slave
1 channel per A/B =
1 channel per A/B slave
OR:
channels 1 + 3 per single slave
1 channel =
1 channel per single slave
OR:
1 channel per A slave
2 channels =
2 channels per single slave
OR:
2 channels per A slave
4 channels =
4 channels per single slave
OR:
2 channels per A/B slave
3 Set the number of analogue channels per output slave
► Set the following parameter as required:
Parameter
Meaning
Possible values
[Analog.
channels/O-slave]
Number of analogue
channels transmitted per
output slave
1 channel per A/B =
1 channel per A/B slave
OR:
channels 1 + 3 per single slave
1 channel =
1 channel per single slave
OR:
1 channel per A slave
2 channels =
2 channels per single slave
OR:
2 channels per A slave
4 channels =
4 channels per single slave
OR:
2 channels per A/B slave
