7.1.5 Connectors
ifm electronic gmbh ● Friedrichstraße 1 ● 45128 Essen We reserve the right to make technical alterations without prior notice! 22 Nov� 2017CR720S / page 11
CR720S Technical data
Control systems
Connectors
EPS Source
Product Scale Drawing
Frame Size: 80 mm x 49,5 mm
Original Scale Drawing (MTD)
P_MZ_e100_0093
Scale: 1:2
CAN1 +
RS-232
ETH1
ETH0CAN0Connector A Connector B
CAN0 M12 socket, 5 poles, A-coded
1: not used:
2: not used:
3: GND_COM
4: CAN0_H
5: CAN0_L
CAN1 + RS-232 M12 socket, 5 poles, A-coded
1: RS-232_TxD
2: RS-232_RxD
3: GND_COM
4: CAN1_H
5: CAN1_L
ETH0 / ETH1 M12 socket, 4 poles, D-coded
1: TxD+
2: RxD+
3 : TxD-
4: RxD-
Connector A AMP, 81-pole, A-coded
1-81: see wiring
connector A
EPS Source
Product Scale Drawing
Frame Size: 80 mm x 49,5 mm
Original Scale Drawing (MTD)
P_MZ_e100_0093
Scale: 1:2
12
3
456 24
4325
44
63
62
81
Connector B AMP, 81-pole, B-coded
1-81: see wiring
connector B
EPS Source
Product Scale Drawing
Frame Size: 80 mm x 49,5 mm
Original Scale Drawing (MTD)
P_MZ_e100_0093
Scale: 1:2
12
3
456 24
4325
44
63
62
81
