6.5 Installation of the unit with coaxial probe in the tank
► Seal the process connection:
- For pipes with G¾ process connection: slide the supplied seal onto the thread
of the coaxial pipe�
- For pipes with ¾'' NPT process connection: apply a suitable sealing material
(e�g� Teflon tape)�
► Screw the unit with the coaxial pipe into the tank and tighten it�
6.6 Alignment of the sensor housing
After installation, the sensor housing can be aligned� It can be rotated
without restriction� Even if rotated several times there is no risk of damage
to the unit�
