IFM LR8000 - Page 6

6
Rods Length (cm / inch) Order number
70 / 27�6 E43205
100 / 39�4 E43207
120 / 47�2 E43208
140 / 55�1 E43209
160 / 63�0 E43210
Coaxial pipes with
process connection G¾
Length (cm / inch) Order number
24 / 9�5 E43211
30 / 11�8 E43228
45 / 17�7 E43212
50 / 19�7 E43229
70 / 27�6 E43213
100 / 39�4 E43214
120 / 47�2 E43215
140 / 55�1 E43216
160 / 63�0 E43217
Coaxial pipes with
process connection ¾" NPT
Length (cm / inch) Order number
45 / 17�7 E43218
70 / 27�6 E43219
100 / 39�4 E43220
120 / 47�2 E43223
140 / 55�1 E43224
160 / 63�0 E43221
Flange plates Size / process connection Order number
73 - 90 / G¾ E43201
65 - 80 / G¾ E43202
Only use rods and coaxial pipes from ifm electronic gmbh� The optimum
function is not ensured when using components from other manufacturers�
