8.2 Explanation of the menu
SP1/rP1 Upper / lower limit value for system pressure at which OUT1 switches�
FH1/FL1 Upper / lower limit for the acceptable range (monitored by OUT1)�
SP2/rP2 Upper / lower limit value for system pressure at which OUT2 switches�
FH2/FL2 Upper / lower limit for the acceptable range (monitored by OUT2)�
EF Extended functions / opening of menu level 2�
rES Restore factory settings�
dS1 Time delay for SP1 / FH1�
dS2 Time delay for SP2 / FH2�
dr1 Time delay for rP1 / FL1�
dr2 Time delay for rP2 / FL2�
ou1 Output function for OUT1:
• Switching signal for the pressure limit values: hysteresis function [H ��] or
window function [F ��], either normally open [� no] or normally closed [� nc]�
ou2 Output function for OUT2:
• Switching signal for the pressure limit values: hysteresis function [H ��] or
window function [F ��], either normally open [� no] or normally closed [� nc]�
• Diagnostic signal [ou2] = diA�
uni Standard unit of measurement for system pressure�
Lo Maximum value memory for system pressure�
Hi Minimum value memory for system pressure�
dAP Damping for the switching outputs�
coF Manually enter the zero point calibration�
tcoF Teach zero-point calibration�
diS Update rate and orientation of the display�
cLor Colour of the digital display (permanent or alternating with switching status
OUT1)�
