IFT Evolve 300 CX - Page 44

44
 Thegainvalueissettoohighifthenose/tailofthehelicoptertwitchesquickly
fromsidetosidewheninhoverand/orfastforward/backward/sidewaysflight.If
youfindthistobethecaseforyourhelicopter,decreasethegyrogainvaluein
smallincrementsuntilthenose/tailofthe
helicopternolongertwitchesquickly
fromsidetoside.

Turnthegyrogaintrimmerpotcounterclockwise(‐)todecreasegyrogain.

 Thegainvalueissettoolowwhenthenose/tailofthehelicopterfeels‘loose’
duringflight,requiringconstantleftandrightruddercontrolinputsto
maintain
heading.Ifyoufindthistobethecaseforyourhelicopter,increasethegyrogain
valueinsmallincrementsuntilfew,ifany,leftandrightruddercontrolinputsare
requiredtomaintainheading.

Turnthegyrogaintrimmerpotclockwise(+)toincreasegyrogain.

IMPORTANTNOTE:
YoumustalwaysdisconnecttheLiPoflightbatteryfromthe3‐in‐1
controlunitbeforemakinganyadjustmentstothegyrogaintrimmerpot.Anychangesin
theposition/settingofthepotwillnottakeeffectuntilthenexttimethecontrolunitis
poweredon/initialized.

NOTE:Thereis
asmallholelocatedundertheorange‐colored‘stripe’decalappliedtothe
windshieldthatcanbeusedtoaccessthegyrogaintrimmerpotwithoutremovingthebody.
Startingatthetopedge,slowlyandcarefullypullthedecalawayfromthewindshielduntil
youreachthehole.

Also,
youmustusethepropersizeandtypeof‘straight’bladescrewdriver(preferablywitha
plastictip)tocarefullyturn/adjustthepot.Useofanimpropersizeandtypeofscrewdriver
and/ortoomuchforcecandamagethetrimmerpot.










