IFT Evolve 300 CX - Upper Main Rotor Blade Tracking

45



TheEvolve300CXisequippedwithanadjustable‐lengthlinkagethatconnectsthestabilizer
flybartothemainrotorbladegripsfortheuppersetofrotorblades.Thislinkageallowsyou
toadjustthe‘tracking’oftheuppermainrotorbladesforsmootherandmorestableflight
performance.



Youcanchecktheuppermainrotorbladetrackingwiththehelicopteronthegroundorinthe
airwhileflying.Also,werecommendhavinganassistantonhandtohelp‘sight’theblades
(especiallyifyou’llbecheckingthebladetrackingwhileflying).

CAUTION:YOUMUSTMAINTAIN
ASAFEDISTANCEFROMTHEHELICOPTER
(APPROXIMATELY10FEET/3METERSORMORE)ANDWEARAPPROPRIATEEYE
PROTECTION(SUCHASSAFETYGOGGLES)WHENCHECKINGTHEUPPERMAINROTOR
BLADETRACKING.

Tocheckthetrackingraisetheleft‐hand/throttlestickslowlytoincreasethespeed/RPMsof
therotorbladesuntiljustbefore
thehelicoptertakesoff(tochecktrackingontheground)or
tomaintainastablehover(tochecktrackingwhileflying).

Oncetherotorbladeshavebeenbroughtuptotheappropriatespeed/RPMs,checktoseeif
thetipsoftheuppermainrotorbladesaretrackinginthesame
planeornot.

