IFT Evolve 300 CX - Proportional MIX Trimmer Pot

42



The3‐in‐1controlunitisequippedwitha‘PROPORTIONAL’mixtrimmerpotthatadjuststhe
amountof‘mixing’betweenthemotors.Thisallowsyoutofine‐tunetheruddertrim/sub‐
trimtohelppreventthenoseofthehelicopterfromdriftingtotheleftorrightwhenin
hover
andwhenclimbing/descending.



NOTE:AllRTFandRFRversionEvolve300CXhelicoptersaretest‐flownatthefactory.And
duringeachtestflighttheposition/settingfortheproportionalmixtrimmerpotistypically
adjustedtoprovideverygoodtrimandperformanceoverall.Thisinmindwestrongly
recommendthatifyoudecideto
adjusttheposition/settingofthepotthatyouuseasuitable
marker,paint,etc.tomarkthepositionitwasadjustedtoatthefactorybeforeproceeding
(thatwayyoucanquicklyandeasilyreturntothefactorysettingifneeded).


Establishastablehoverand,withtheruddertrimlever‘centered’andnorudder
controlinput,checktoseeifthenoseofthehelicopterisdriftinginonedirectionor
theother.Ifthenoseofthehelicopterisdriftingtotheleft,turntheproportionalmix
trimmerpotclockwise
(+)asneededtominimize/eliminatethedrifting.


Ifthenoseofthehelicopterisdriftingtotheright,turntheproportionalmixtrimmer
potcounterclockwise(‐)asneededtominimize/eliminatethedrifting.

IMPORTANTNOTE:YoumustalwaysdisconnecttheLiPoflightbatteryfromthe3‐in‐1
controlunitbeforemakinganyadjustmentstotheproportionalmixtrimmerpot.Any
changesintheposition/settingofthepotwillnottakeeffectuntilthenexttimethecontrol
unitispoweredon/initialized.
Pro
p
ortional Mix Trimmer Pot
