Binding/linkingistheprocessofprogrammingthereceivertorecognizetheGloballyUnique
Identifier(GUID)codeofasinglespecifictransmitter.Thesestepsoutlinethebinding/linking
processoftheMP5H5‐ChannelHelicopterTransmitter(IFLH1305)andcompatible6‐Channel
ParkFlyerReceiver(IFLH1306)includedwithRTFversionmodels:


Providepowertothereceiverthroughthe3‐in‐1controlunit(recommended)or
directlyusinga4.8–6.0Vbattery/DCpowersource.DONOTconnectthe3‐Cell/3S
11.1VLiPoflightbatterytothereceiverdirectlyasvoltagesabove6.0Vcandamage
thereceiverpermanently.


Ifthereceiverisnotbound/linkedtothetransmittertheorangeLEDindicatorwillblink
slowly.Pressthebind/linkbuttononthesideofthereceiverandtheLEDindicatorwill
begintoblinkrapidly(withashortpauseafterblinkingthreetimes).Thisindicatesthe
receiverhasenteredbind/linkmode.


NOTE:Duringthebinding/linkingprocessthe‘fail‐safe’positionsfortheradiosystemare
set.Intheeventthereceiverlosessignalfrom/connectiontothetransmitterthethrottle
channelwilldefaulttothepositionthatwassetduringthebinding/linkingprocessandall
otherchannelswillholdthelastpositionthey
werein.Also,ifthereceiveriseverpowered
onbeforethetransmitter,allchannels(exceptforthrottlewhichwillnotgeneratea‘pulse’
inordertopreventthecontrolunitfromarming)willdefaulttothepositionsthatwereset
duringthebinding/linkingprocess.

IMPORTANTNOTE:Beforecontinuingwiththebinding/linkingprocessyouMUSTmovethe
transmittercontrolsticks,trimleversand‘GEAR’switchtothepositionsyouprefertouse
asthe‘fail‐safe’positionsforeachchannel/function.WESTRONGLYRECOMMEND
LOWERINGTHELEFT‐HAND/THROTTLESTICKANDTHETHROTTLETRIMLEVERTOTHEIR
LOWEST
POSSIBLEPOSITIONSwhilealsocenteringthesticksandtrimleversfortherudder,
elevatorandaileronchannels/controls.


Whilethereceiverisinbind/linkmodeturnthetransmitteron.Eachtimethe
transmitteristurnedonitwillautomaticallyenterthebind/linkmodebrieflyas
indicatedbytheLEDnearthebottomleft‐handcornerofthetransmitter.TheLEDwill
blinkrapidlywhenthetransmitterisinbind/link
mode,andafterafewsecondsitwill
switchtoglowsolidredindicatingthatthebinding/linkingprocessiscomplete.Also,
duringthebinding/linkingprocesstheLEDindicatoronthereceiverwillblinkslowly
thenswitchtoglowsolidorangewhentheprocessiscomplete.Youshouldnowhave
full
controlofthereceiver/controlunit/servos(ifyoudonothavecontrolrepeatall
stepsofthebinding/linkingprocessagain).

