IFT Evolve 300 CX - Required to Complete; Installing the Receiver (RFR Version Only)

6



TheEvolve300CXRTF(Ready‐To‐Fly)versionincludeseverythingneededtoflyrightoutof
thebox.There’snothingextratobuyorprovide!

TheEvolve300CXRFR(Ready‐For‐Receiver)versionrequiresthefollowingitems:

 5+channeltransmitter(withsuitablerangeifyouplantoflyoutdoors)

 5+channelreceiver(compatiblewiththetransmitterthatwillbeused)

 3‐Cell/3S11.1V800mAhLiPobattery(IFLB8003S20Jorsimilartofitthebatteryholder)

 LiPobatterycharger(compatiblewiththebatterythatwillbeused)




TheEvolve300CXRFR(Ready‐For‐Receiver)versionisfully‐assembledandtest‐flownatthe
factory(likeallRTFversionmodels).Aftertestflyingiscompletethereceiverisremovedand
thewireleadsthatwillconnecttoyourchosenreceiverareleftlocatedinsidethenoseofthe

body.

Selectasuitable5+channelreceivercompatiblewiththetransmitteryou’vechosentouse
thenlocatethewireleadsandconnectors(5total)thatmustbeconnectedtothereceiver.
Dependingontheavailablelengthofthewireleads,aswellasthesizeandshapeofyour
receiver,determineif
thereceivercanbemountedonthetoporbottomoftheplastic
mountingtrayattachedtothemainframe(locatedinsidethebodynearthenoseofthe
helicopter).Whenpossiblewerecommendinstallingthereceiverontopofthetrayandin
frontofthefactory‐installed3‐
in‐1controlunit.

Checkthefitofyourreceiverinthechosenmountingpositionwhileensuringthebest
possibleorientationfortheantenna(s)andthewireleads/connections.Afterdeterminingthe
bestmountingpositionremovethereceiverandapplyoneortwosectionsoftheincluded
two‐sidedfoamtapeonthesidethatwill
bemountedtothetray.Next,locateallfive(5)of
thewireleadsandconnectorsthatmustbeconnectedtothereceiver.Eachwireleadis
labeledaccordingtothechannelofthereceiveritmustbeconnectedto.Refertothe
markingsonthereceiver,themarkingson
thelabelsandthelistbelowtomaketheproper
connections(youmayalsoneedtorefertotheinstructionmanualforthereceiverand/or
transmitteryou’vechosentouse).

NOTE:It’simportanttoensurecorrectpolaritywhenpluggingthewireleads/connectors
intothereceiver.Refertothemarkingsonthereceiver(ortheinstructionmanualforthe
receiver)toidentifywhichpinsaccepttheblackcolor(negative/ground),redcolor
(positive)andothercolor(signal)wireleads.
