7
๏ท Connect๎the๎โThrottle๎(THRO)โ๎lead๎to๎the๎โthrottleโ๎channel๎of๎the๎receiver๎
(channel๎3/CH3๎for๎Futaba๎and๎Hitec๎transmitters/receivers)๎๎
๎
๏ท Connect๎the๎โAileron๎(AILE)โ๎lead๎to๎the๎โaileronโ๎channel๎of๎the๎receiver๎
(channel๎1/CH1๎for๎Futaba๎and๎Hitec๎transmitters/receivers)๎๎
๎
๏ท Connect๎the๎โElevator๎(ELEV)โ๎lead๎to๎the๎โelevatorโ๎channel๎of๎the๎receiver๎
(channel๎2/CH2๎for๎Futaba๎and๎Hitec๎transmitters/receivers)๎๎
๎
๏ท Connect๎the๎โRudder๎(RUDD)โ๎lead๎to๎the๎โrudderโ๎channel๎of๎the๎receiver๎
(channel๎4/CH4๎for๎Futaba๎and๎Hitec๎transmitters/receivers)๎๎
๎
๏ท Connect๎the๎โGear๎(GEAR)โ๎lead๎to๎the๎โgearโ๎channel๎of๎the๎receiver๎
(channel๎5/CH5๎for๎Futaba๎and๎Hitec๎transmitters/receivers)๎๎
๎
NOTE:๎The๎โGearโ๎lead๎can๎also๎be๎connected๎to๎almost๎any๎channel๎that๎features๎a๎
suitable๎2โposition๎switch๎(recommended),๎โsliderโ๎switch๎or๎rotating๎knob๎on๎the๎
transmitter.๎This๎channel๎is๎used๎to๎control๎the๎Collision๎Avoidance๎Technology๎(C.A.T.)๎
module๎in๎order๎to๎turn๎the๎technology๎on๎or๎off๎remotely๎from
๎the๎transmitter๎(please๎
see๎the๎โCollision๎Avoidance๎Technologyโ๎section๎of๎this๎manual๎for๎more๎information).๎
๎
After๎making๎the๎proper๎connections๎itโs๎a๎good๎idea๎to๎test๎the๎controls๎before๎installing๎the๎
receiver.๎Please๎see๎the๎โFlight๎Controls๎and๎Trimmingโ๎and๎โCollision๎Avoidance๎Technologyโ๎
sections๎of๎this๎manual๎for๎more๎information.
๎
๎
IMPORTANT๎NOTE:๎We๎strongly๎recommend๎to๎disconnect๎the๎wire๎leads/connectors๎for๎
BOTH๎motors๎from๎the๎3โinโ1๎control๎unit๎whenever๎testing๎the๎controls.๎Make๎note๎of๎the๎
positions๎and๎polarities๎of๎the๎wire๎leads/connectors๎before๎disconnecting๎them๎in๎order๎to๎
ensure๎you๎can๎reconnect๎them๎for๎proper๎operation๎after
๎the๎control๎test๎is๎complete๎and๎
before๎proceeding๎with๎your๎first๎flight.๎
๎
After๎confirming๎the๎controls๎are๎responding๎properly,๎carefully๎route๎the๎receiver๎and๎wire๎
leads๎into๎the๎nose๎of๎the๎helicopter๎and๎mount๎the๎receiver๎to๎the๎tray๎using๎the๎twoโsided๎
foam๎tape.๎In๎most๎cases๎it๎will
๎typically๎be๎best๎to๎route๎the๎receiver๎and๎wire๎leads๎through๎
the๎opening๎in๎the๎bottom๎of๎the๎body,๎but๎in๎some๎cases๎(depending๎on๎the๎size/shape๎of๎
the๎receiver๎and๎the๎available๎length๎of๎the๎wire๎leads)๎it๎may๎be๎possible๎to๎route๎them๎
through๎one๎of๎the๎โwindowโ๎
openings๎on๎the๎sides๎of๎the๎body.๎
๎
With๎the๎receiver๎mounted๎on๎the๎tray๎ensure๎that๎all๎connections๎are๎secure๎and๎that๎the๎
antenna(s)๎and๎wire๎leads๎are๎clear๎of๎any๎moving๎parts,๎electronics๎or๎other๎
components/parts๎that๎could๎damage๎them๎and/or๎have๎a๎negative๎effect๎on๎the๎radio๎
system๎performance,
๎range,๎etc.๎We๎recommend๎referring๎to๎the๎instruction๎manual๎for๎the๎
receiver๎and/or๎transmitter๎for๎more๎information.๎
