IGEA I-ONE - User Manual
Page 17
Electrostatic Discharge (ESD)
IEC 61000-4-2
± 8 kV contact
± 15 kV air
Test Level
IEC 60601-1-2
Any environment including at home
Irradiated RF
IEC 61000-4-3
10 V/m
80 MHz to 2.7 GHz
Test Level
IEC 60601-1-2
Any environment including at home with portable
and mobile RF devices kept as far away from the I-
ONE - CBA04 model as possible, including
connecting cables.
Minimum distance 30 cm
Fast electrical
transients/bursts
IEC 61000-4-4
± 2 kV per supply line
± 1 kV per input/output
line
Test Level
IEC 60601-1-2
Any environment including at home
Surges
IEC 61000-4-5
± 1 kV between phases
± 2 kV between phase
and earth
Test Level
IEC 60601-1-2
Any environment including at home
Conducted RF
IEC 61000-4-6
3 V eff.
150 kHz to 80 MHz
6 V - ISM frequencies
and amateur radio
band
Test Level
IEC 60601-1-2
Any environment including at home with portable
and mobile RF devices kept as far away from the I-
ONE - CBA04 model as possible, including
connecting cables.
Minimum distance 30 cm
Voltage dips, short
interruptions and voltage
variations on power supply
input lines
IEC 61000-4-11
10 ms - 0% at 0°, 45°,
90°, 135°, 180°. 225°,
270°, 315°
20 ms - 0% at 0°
500 ms - 70% at 0°
5 s - 0%
Test Level
IEC 60601-1-2
Any environment including at home
Magnetic field at mains
frequency (50/60 Hz)
IEC 61000-4-8
30 A/m
Test Level
IEC 60601-1-2
Any environment including at home
10.3 Immunity to proximity fields from RF wireless communication devices
Portable or mobile RF communication devices that may be present in the home such as wireless telephones,
mobile phones, devices for wireless connection to the internet and similar, must be kept away from the I-ONE
device to avoid the risk of interference. The recommended minimum separation distance depends on the output
power of the RF device and the transmission frequency. The user can help prevent electromagnetic interference
by maintaining a minimum distance between portable and mobile RF communication systems and the I-ONE using
the table below as a reference.
Test
Frequency
(MHz)
Band
(MHz)
Type of Service
Modulation
Maximum
Power
(W)
Distance
(m)
Test immunity
level
(V/m)
385
380 -390
TETRA 400
Pulse
modulation
18 Hz
1.8
0.3
27
450
430 - 470
GMRS 460, FRS 460
FM
± 5 kHz deviation
1 kHz sine
2
0.3
28
710
704 - 787
LTE Band 13,
17
Pulse
modulation
217 Hz
0.2
0.3
9
745
780
810
800 - 960
GSM 800/900,
TETRA 800, iDEN 820,
CDMA 850,
LTE Band 5
Pulse
modulation
18 Hz
2
0.3
28
870
930
1 720
1700 -1990
Pulse
2
0.3
28
IGEA I-ONE - User Manual
Page 18
1 845
GSM 1800; CDMA
1900; GSM 1900;
DECT;
LTE Band 1, 3,
4, 25; UMTS
modulation
217 Hz
1 970
2 450
2400 -2570
Bluetooth, W LAN,
802.11 b/g/n,
RFID 2450,
LTE Band 7
Pulse
modulation
217 Hz
2
0.3
28
5 240
5100 -5800
W LAN 802.11 a/n
Pulse
modulation
217 Hz
0.2
0.3
9
5 500
5 785
The immunity levels given in the table are met as long as the device is kept at a distance of at least 30 cm from any
possible source of RF interference.
The I-ONE - CBA04 complies with all test levels with a distance >= 30 cm.
