iHome IM14 - Controls Overview

Controls Overview
Left Panel
Right Panel
Top Panel
Bottom Panel
Alarm On/Off
Button
Power
Button
Power
Indicator
LED
Snooze
Button
Power ON
Indicator
LED (blue)
Alarm ON
Indicator LED
(green)
Alarm Set
Button
Time Set
Button
Button
Lock Switch
Plus/Minus Setting
Buttons
DC jack
Aux-in jack
1 Amp USB
Charging Port
(under rubber cover)
Display
Backup Battery
Compartment
(Use a Phillips
screwdriver to loosen
screw, then remove door)
AUX-IN DC IN
