3
AUX-IN DC IN
Set Up
Connecting to Power Source
Connect the AC adaptor to the DC jack located on left end of the unit. Connect plug into a
working wall outlet that is not controlled by a wall switch. The display on the unit will show 12:00
PM. The unit does not operate on battery (the battery back up system maintains clock settings
during power failures). Remove battery pull tab before operation.
Display
Indicates what days alarm is set for:
7 Days (every day), Week Day (Mon. - Fri.)
or Week End (Saturday and Sunday)
When blinking, indicates backup batteries
should be replaced.
When lit, indicates Button Lock is active
When lit, indicates alarm is active
Note: This unit has motion detection that will
turn on the display for 15 seconds when the
unit is moved.
Day of the week indicator
When lit, indicates time
displayed is PM
(does not appear in
24 hour display mode)
Time display
Alarm Time display
