Technical data
General data
Nominal voltage VDC 24
Power input W 24
Motor rating output W 4�8
Operating mode Automatic / Manual
Guard rail lo-vi / me-vi, hi-vi I, hi-vi II
Spindle set lo-vi / me-vi, hi-vi I, hi-vi II
Support rod diameter mm 16
Basic container volume ml 600 (low form beaker)
Interface USB, RS 232
Permissible ambient temperature °C + 5 ��� + 40
Permissible relative humidity %
80
IP code according to EN 60529 IP 40
Dimensions (W × D × H) (without support rod) mm 130 × 176 × 305
Weight kg 2�3
Operation at a terrestrial altitude m max� 2000
Viscosity measuring function
Max� measuring viscosity: lo-vi
me-vi
hi-vi I
hi-vi II
mPa·s 6�0 x 10
6
40 x 10
6
80 x 10
6
320 x 10
6
Viscosity accuracy % ± 1 of full scale range
Viscosity repeatablility % ± 0�2 of full scale range
Speed range rpm 0�01 ��� 200
Speed setting accuracy: in range 0�01��� 1 rpm
in range 1��� 200 rpm
rpm 0�01
0�1
Speed display TFT LCD
Max� permitted density
kg/dm
3
9�999
Direction of rotation counterclockwise
Torque measuring function
Torque display TFT LCD
Torque measurement M%
Overload protection yes
Temperature measuring function
Connection for external temperature sensor PT 100
Working temperature °C -100 ��� 300
Working temperature display TFT LCD
Temperature measurement resolution K 0�1
Temperature measurement accuracy:
-100 °C ��� +150 °C
150 °C ��� +300 °C
K 0�1+tolerance PT 100 (DIN EN 60751 class A)
0�2+tolerance PT 100 (DIN EN 60751 class A)
Timer function
Timer display TFT LCD
Timer setting range min� 0 ��� 6000
Power supply
Input voltage VAC
A
Hz
100 ��� 240
0�6
50 / 60
Output VDC
W
24 VDC
24 LPS (limited power source)
Protection class 2 (double insulated)
Accessories
› ROTAVISC lo-vi standard spindle series
› ROTAVISC me-vi standard spindle series
› VAN-1: Van spindle
› DINS-1: DIN adapter
› ELVAS-1: Extremely low viscosity adapter
› VOLS-1: Low volume adapter
› SAS-1: Spiral adapter
› Standard silicon oil CAL-0-5 to CAL-0-10000
For further accessiores see www.ika.com�
/// Repair:
› Please only send devices in for repair that have been cleaned and are free of materials which
might present health hazards�
› For repair, please request the “Safety Declaration (Decontamination Certificate)” from
IKA or use the download printout of it from IKA website at www.ika.com�
› If your appliance requires repair, return it in its original packaging� Storage packaging is not
sucient when sending the device - also use appropriate transport packaging�
