Warranty
› In accordance with IKA warranty conditions, the warranty period is 24 months� For claims
under the warranty please contact your local dealer� You may also send the machine direct to
our factory, enclosing the delivery invoice and giving reasons for the claim� You will be liable
for freight costs�
› The warranty does not cover worn out parts, nor does it apply to faults resulting from improp-
er use, insucient care or maintenance not carried out in accordance with the instructions in
this operating manual�
Appendix A “Range coecient“
Using the “Range coecient“, the maximum viscosity that can be measured with a specific
spindle can be quickly determined�
1� Identify the selected spindle and the viscometer spring sensor (lo-vi/me-vi/hi-vi l/hi-vi ll)�
2� Find the “Range coecient“ in below table�
3� Divide the range coecient by the spindle speed�
E�g�: If you choose me-vi viscometer with SP-6 spindle: Range coecient is 10,000�
At speed of 10 rpm, the maximum viscosity (mPa·s) is 10,000/10=1,000 mPa·s
Spindle lo-vi me-vi hi-vi l hi-vi II
SP-1 6,000 64,000 128,000 512,000
SP-2 30,000 320,000 640,000 2,560,000
SP-3 120,000 1,280,000 2,560,000 10,240,000
SP-4 600,000 6,400,000 12,800,000 51,200,000
SP-5 1,200,000 12,800,000 25,600,000 102,400,000
SP-6 937 10,000 20,000 80,000
SP-7 3,750 40,000 80,000 320,000
SP-8 9,375 100,000 200,000 800,000
SP-9 18,750 200,000 400,000 1,600,000
SP-10 37,500 400,000 800,000 3,200,000
SP-11 93,750 1,000,000 2,000,000 8,000,000
SP-12 375,000 4,000,000 8,000,000 32,000,000
S-SP 98,400 1,050,000 2,100,000 8,400,000
ELVAS-SP 600 6,400 12,800 51,200
DIN-SP-5 1,144 12,200 24,400 97,600
DIN-SP-6 3,420 36,500 73,000 292,000
DIN-SP-7 11,340 121,300 242,600 970,400
VOL-SP-2.1 117,200 1,250,000 2,500,000 10,000,000
VOL-SP-3.8 46,880 500,000 1,000,000 4,000,000
VOL-SP-4.2 120,000 1,280,000 2,560,000 10,240,000
VOL-SP-6.7 3,000 32,000 64,000 256,000
VOL-SP-7.1 4,688 50,000 100,000 400,000
VOL-SP-16.1 480,000 5,120,000 10�240,000 40,960,000
VOL-SP-10.4 23,440 250,000 500,000 2,000,000
VOL-SP-11.0 46,880 500,000 1,000,000 4,000,000
VOL-SP-13.5 93,750 1,000,000 2,000,000 8,000,000
VOL-SP-9.0 30,000 320,000 640,000 2,560,000
VOL-SP-9.4 60,000 640,000 1,280,000 5,120,000
