User’s Manual REVEXplus, REVEXplus USB
Copyright © 2006–2019 ILLKO, s.r.o.
20
3
START
Cal
LOCK
STARTSTART STARTSTART
Test socket 1 energizing
(Locking of the START
key)
4
Switch on tested
appliance
Measurement
5
Switch off tested appliance
End of measurement
6
START
Test socket 1 deenergizing
(Unlocking of the START
key)
7
IPE
M
mA
cos 
A V
VA
W
K   
PROTECT
EXT
INV
L-N reversal in test socket 1
8
START
Cal
LOCK
START START
Test socket 1 energizing
(Locking of the START
key)
9
Switch on tested
appliance
Measurement
10
Switch off tested appliance
End of measurement
11
START
Test socket 1 deenergizing
(Unlocking of the START
key)
Fig. 8 – Leakage current measurement
Step 1 - preparation for measurement
• Select the I
PE
function or the I

function: pres either the I
PE
 key or the I

 key and
release it. Symbol „- -“ is displayed and indicators either (I
PE
) or (I

) and (mA) light
up.
• Connect tested appliance: plug in its mains plug to test socket 1.
Step 2 – measurement with L-N default
• Press and release either the I
PE
 or the I

 key. If the indicator (INV) lights up, then
press and release corresponding key once more in order to turn off the indicator (INV).
• Press the START key. It is recommended to lock the measurement - press the
START key and then press the LOCK key. Release both keys. The presence of
