User’s Manual REVEXplus, REVEXplus USB
Copyright © 2006–2019 ILLKO, s.r.o.
25
Fig. 12 –Touch leakage current of protective class I appliances measurement
4.7. Mains voltage and current consumption – U, I
Function U measures L-N voltage in mains outlet from which the REVEXplus is
powered.
Function I measures current consumption of tested appliance connected to test socket 1.
1
IPE
M
mA
cos

A V
VA
W
K   
PROTEC T
EXT
INV
Function selection
2
Connect tested appliance
Connect tested appliance to
test socket 1
3
START
Cal
LOCK
STARTSTART STARTSTART
Test socket 1 energizing
(Locking of the START
key)
4
Switch on tested
appliance
PE current during operation
measurement
5
ID
Memorizing of PE current
during operation.
6
Press the test tip
connected to the I
D
terminal against
exposed conductive
part of tested
appliance.
Measurement of touch
leakage current
(PE current during operation
is automatically subtracted;
displayed result is thus
correct).
7
Switch off tested
appliance
End of measurement
with L-N default
8
START
Test socket 1 deenergizing
(Unlocking of the START
key)
9
IPE
M
mA
cos 
A V
VA
W
K   
PROTECT
EXT
INV
L-N reversal in test socket 1
Proceed once more with above described procedure from Step 3 to Step 8.
