6. TECHNICAL SPECIFICATION
6.1. General data
Protective class .......... II (double insulation)
Over voltage class ............................. CAT II
Pollution degree .......................................... 2
Degree of protection ............................. IP 20
Reference condition:
Line voltage . 230V1%/50Hz,60Hz 1%
Ambient temperature ............. (23  2) C
Humidity ............ 45  55 % RH @ 23 C
Position ...................................... arbitrary
Operating condition:
Line voltage 230V10%/50Hz,60Hz 1%
Ambient temperature ............ 0C  40C
Humidity ............ max. 75 % RH @ 23C
(condensation not allowed)
Elevation..............................max. 2000 m
Max. supply current .............................. 16 A
(it depends on tested appliance)
Quiescent current ............................  50 mA
Dimensions (w x d x h) . 150 x 195 x 50 mm
Mass (without accessories) .................... 1 kg
Storage temperature / storage humidity.........
.......................-10  50C / max. 75% RH
Case resistance to temperature ............. 70C
PE test ........................................... automatic
PC connection (REVEXplus USB only).USB
6.2. Functions
Earth bond 200 mA
Entire measuring range
0.000 ÷ 20.00 
Measuring sub range
0.000 ÷ 0.999 
Resolution
0.001 
Reference error
(1 % of R + 5 D)
Operating error
(2 % of R + 5 D)
Measuring sub range
1.00 ÷ 20.00 
Resolution
0.01 
Reference error
(1 % of R + 3 D)
Operating error
(2 % of R + 3 D)
Operating range of use
(according to EN 61557-4)
0.018 ÷ 20.00 
Open-circuit voltage
AC 5 ÷ 12 V
Test current (R ≤ 2 )
≥ AC 200 mA
Test lead compensation
yes (up to 2 )
PE current during operation
Entire measuring range
0.000 ÷ 10.00 mA
Measuring sub range
0.000 ÷ 1.499 mA
Resolution
0.001 mA
Reference error
(1 % of R + 5 D)
Operating error
(2 % of R + 8 D)
Measuring sub range
1.50 ÷ 10.00 mA
Resolution
0.01 mA
Reference error
(1 % of R + 5 D)
Operating error
(2 % of R + 5 D)
Test voltage
line voltage
Frequency characteristic
of internal test circuitry
according to EN 61010
Functionality test
0.090 ÷ 0.110 mA
Insulation resistance
Entire measuring range
0.000 k ÷ 100.0 M
Measuring sub range
0.0 k ÷ 999.9 k
Resolution
0.1 k
Reference error
(2 % of R + 8 D)
Operating error
(3 % of R + 8 D)
Measuring sub range
1.000 M ÷ 3.999 M
Resolution
0.001 M
Reference error
(2 % of R + 8 D)
Operating error
(3 % of R + 8 D)
Measuring sub range
4.00 M ÷ 19.99 M
Resolution
0.01 M
Reference error
(2 % of R + 8 D)
Operating error
(3 % of R + 8 D)
Measuring sub range
20.0 M ÷ 100.0 M
Resolution
0.1 M
Reference error
(4 % of R + 15 D)
Operating error
(5 % of R + 15 D)
Operating range of use
(accord. to EN 61557-2)
3.0 k ÷ 100.0 M
Nominal output voltage Un
DC 500 V
Open-circuit voltage
(-0%, + 50%) Un
Nominal test current
≥ DC 1 mA
Short-circuit current
< DC 10 mA
Functionality test
2.000 ÷ 2.600 M
Mains voltage U
L-N
Measuring range
207.0 ÷ 253.0 V
Resolution
0.1 V
Reference error
(1 % of R + 2 D)
Operating error
(2 % of R + 2 D)
