User’s Manual REVEXplus, REVEXplus USB
Copyright © 2006–2019 ILLKO, s.r.o.
35
Differential leakage current
Entire measuring range
0.000 ÷ 10.00 mA
Measuring sub range
0.000 ÷ 0.999 mA
Resolution
0.001 mA
Reference error
(1 % of R + 5 D + X*)
Operating error
(2 % of R + 10 D+ X*)
Measuring sub range
1.00 ÷ 10.00 mA
Resolution
0.01 mA
Reference error
(1 % of R + 5 D + Y*)
Operating error
(2 % of R + 5 D + Y*)
Test voltage
line voltage
Frequency characteristic
of internal test circuitry
according to EN 61010
Functionality test
0.090 ÷ 0.110 mA
*X = S (0.01 IΔ + 0,005) *Y = S (0.001 IΔ + 0,005)
S….. Apparent power of tested appliance [VA]
IΔ… Displayed value of leakage current [mA]
Substitute leakage current
Entire measuring range
0.000 ÷ 20.00 mA
Measuring sub range
0.000 ÷ 3.999 mA
Resolution
0.001 mA
Reference error
(1 % of R + 8 D)
Operating error
(2 % of R + 8 D)
Measuring sub range
4.00 ÷ 20.00 mA
Resolution
0.01 mA
Reference error
(1 % of R + 5 D)
Operating error
(2 % of R + 5 D)
Nominal open-circuit test
voltage
230 V  15 %
50 Hz ÷ 60 Hz
Short-circuit current
 3,5 mA
Internal resistance of test
voltage source
 80 k
Functionality test
0.090 ÷ 0.110 mA
Leakage current by means of current
clamp or three-phase adapter
Measuring range
0.00 ÷ 20.00 mA
Resolution
0.01 mA
Reference error
(3 % of R + 10 D) (1)
Operating error
(4 % of R + 15 D) (1)
Touch leakage current
Specifications are identical with measuring method
selected for touch leakage current measurement.
Notes:
R - Reading
D - Digit
Some functions have more measuring sub ranges.
These sub ranges are switched over automatically.
Active power, apparent power
Measuring range
5 ÷ 3680 W, VA
Resolution
1 W, VA
Reference error
(3 % of R + 2 D)
Operating error
(5 % of R + 5 D)
Cos φ
Displayed range
0.00 ÷ 1.00
Measuring range
0.40 ÷ 1.00 (2)
Resolution
0.01
Reference error
(1 % of R + 2 D)
Operating error
(2 % of R + 4 D)
Current consumption
Measuring range
0.00 ÷ 16.00 A
Resolution
0.01 A
Reference error
(2 % of R + 5 D)
Operating error
(3 % of R + 5 D)
Current by means of current clamp
Entire measuring range
0.00 ÷ 100.0 A
Measuring sub range
0.00 ÷ 4.99 A
Resolution
0.01 A
Reference error
(3 % of R + 4 D) (1)
Operating error
(4 % of R + 10 D) (1)
Measuring sub range
5.0 ÷ 100.0 A
Resolution
0.1 A
Reference error
(3 % of R + 4 D) (1)
Operating error
(4 % of R + 4 D) (1)
Cos φ by means of current clamp
Displayed range
0.00 ÷ 1.00
Measuring range
0.40 ÷ 1.00 (2)
Resolution
0.01
Reference error
(2 % of R + 2 D) (1)
Operating error
(5 % of R + 5 D) (1)
Active power, apparent power by means of
current clamp
Measuring range
10 ÷ 9999 W, VA
Resolution
1 W, VA
Reference error
(5 % of R + 5 D) (1)
Operating error
(8 % of R + 5 D) (1)
(1) Current clamp or three-phase adapter error has to
be considered additionally
(2) Measuring error is not specified out of this range
