ILMOR 2011 MV8 User Manual

S P E C I F I C A T I O N S A N D
S E R V I C E L O G
S P E C I F I C A T I O N S A N D
S E R V I C E L O G
 EngineModel MV-85.7L MV-86.0L MV-86.2L
 NumberofCylinders V-8 V-8 V-8
 Displacement 5.73L 5.978L 6.16L
 CompressionRatio 9.4:1 9.6:1 10.7:1
 ValveConguration Overheadvalves Overheadvalves Overheadvalves
 FiringOrder 1-8-4-3-6-5-7-2 1-8-7-2-6-5-4-3 1-8-7-2-6-5-4-3
 FuelType Unleaded87-93 Unleaded87-93 Unleaded87-93
  octane octane octane
 FuelShutoff 5,200RPM 5,400RPM 5,400RPM
 EngineWeight(includingV-drive) 1,012lb(460kg) 1,070lb(486kg) 940lb(427kg)
 MATERIALS
 Block CastIron CastIron CastAluminum
 CylinderHead CastIron CastAluminum CastAluminum
 IntakeManifold AluminumUpper AluminumUpper AluminumUpper
  andLower andLower andLower
 ExhaustManifold CastIron CastIron CastIron
Battery(ies) Recommended:
Spiral cell battery with minimum 750 cold cranking amps
Coolant in Half-Closed and Full-Closed Cooling System Required:
ILMOR Antifreeze
Engine Fogging Oil Recommended:
Sta-Bil
®
Fogging Oil
Flame arrestor:
94PE01163
Fuel Required:
Unleaded gasoline, 87 or higher octane, maximum of 10% alcohol
Fuel Recommended:
TOP TIER gasoline, 93 octane
Fuel System Stabilizer Recommended:
Sta-Bil
®
Oil Required:
ILMOR blended synthetic: SAE Grade 5w30, Viscosity ASTM D445 ACEA
Al/Bl, A5/B5; API SM, SL, SJ, EC, CF, CD; ILSAC GF-4 (5 qts. oil change);
no oil additives
Oil Filter:
94MV8V1021
Raw Water Impeller Kit:
Open Cooled - 94MV8V1178
Closed Cooled - 94MV8V1179
Serpentine Belt:
5.7L - 94MV8V1034
6.0L - 94MV8V1044
6.2L - 94MV8V1044
ENGINE
SPECS
Requirements and
Recommendations
2011 ILMOR MV8 Owner’s Manual • Page 53
