OPERATING AND PROGRAMMING INSTRUCTIONS
4-6
dP
- Sail switch (rear the machine) is out of adjustment or has
failed.
- Failed direction of blower or blower is not operation.
- Filter (lint drawer) is not clean.
Ld
- lint drawer is open
LF
- Lint drawer is not closed all the way.
- Lint drawer switch out of proper adjustment.
- Failed lint drawer switch.
- Broken connection / wire in main door or lint drawer circuit.
- Failed 24 VAC transformers.
