SPECIFICATIONS / COMPONENT IDENTIFICATION
2-1
SECTION 2
SPECIFICATIONS / COMPONENT IDENTIFICATION
Model
30 lbs.
50 lbs.
75 lbs.
100 lbs.
120 lbs.
Units of Measurement
Metric
US
Maximum capacity (dry weight)
kg.
lbs.
13.6 (30)
22.7(50)
34(75)
45.4(100)
54.4(120)
Basket Diameter
mm.
inch
762(30”)
922(36.3”)
922(36.3”)
1130(44.5”)
1130(44.5”)
Basket Depth
mm.
inch
762(30”)
762(30”)
910(35.8”)
867(32.4”)
1076(42.4”)
Basket Volume
cu.m
cu.ft
0.35(12.4)
0.51(18)
0.61(21.5)
0.78(30.7)
1.08(38.1)
Basket Motor
kW
HP
0.373(0.5)
0.75(1)
0.75(1)
0.75(1)
0.75(1)
Blower Motor
kW.
HP
0.373(0.5)
0.75(1)
0.75(1)
2.24(3)
2.24(3)
OVERALL DIMENSIONS :
A – Machine Width
mm.
inch
805(31.7”)
980(38.6”)
980(38.6”)
1200(47.2”)
1200(47.2”)
B – Machine Depth
mm.
inch
1140(44.9”)
1150(45.3”)
1270(50”)
1460(57.5”)
1660(65.4”)
C – Machine Height at full
-Gas Model
mm.
inch
1840(72.4”)
1920(75.6”)
1920(75.6”)
2205(86.8”)
2205(86.8”)
-Steam Model
mm.
inch
1999(78.7”)
2040(80.3”)
2040(80.3”)
2318(91.3”)
2318(91.3”)
-Electric Model
mm.
inch
1860(73.2”)
1920(75.6”)
2002(78.8”)
2104(82.8”)
2104(82.8”)
GAS MODEL :
Air Flow
cmm
cfm
17(600)
21.25(750)
25.5(900)
62.3(2200)
62.3(2200)
Gas Consumption
kcal/hr
btu/hr
22680(90000)
32760(130000)
50400(200000)
94500(375000)
94500(375000)
Gas Inlet Connection
NPT
1/2”
1/2”
3/4”
1”
1”
Exhaust Duct Connection
mm.
inch
203(8”)
203(8”)
203(8”)
305(12”)
305(12”)
Net Weight (approx.)
kg.
lbs.
294(648.2)
348(767.2)
379(835.5)
596 (1254.4)
682(1503.6)
Shipping Weight (approx.)
kg.
lbs.
304(670.2)
358(789.3)
390(859.8)
616(1358.0)
702(1547.6)
STEAM MODEL :
Air Flow
cmm
cfm
17(600)
21.25(750)
25.48(900)
77.9(2750)
77.9(2750)
Steam Consumption
kg/hr
lb/hr
40.69(89.7)
71.99(158.7)
101.125(224.25)
203.45(448.5)
203.45(448.5)
Steam Supply Connection
NPT
3/4”
3/4”
3/4”
1-1/4”
1-1/4”
Steam Return Connection
1/2”
1/2”
1/2”
1/2”
1/2”
Exhaust Duct Connection
mm.
inch
203(8”)
203(8”)
203(8)”
305(12”)
305(12”)
Steam Pressure
bar
psi
5.6-8.79(80-125)
5.6-8.79(80-125)
5.6-8.79(80-125)
5.6-8.79(80-125)
5.6-8.79(80-125)
Air Pressure
bar
psi
N/a
N/a
N/a
N/a
6-8(87-116)
Net Weight (approx.)
kg.
lbs.
307(676.9)
362(798)
385(848.8)
609(1342.6)
731(1611.6)
Shipping Weight (approx.)
kg.
lbs.
315(694.5)
372(820.1)
396(873.0)
629(1386.7)
751(1655.7)
ELECTRIC MODEL :
Air Flow
cmm
cfm
17(600)
21.25(750)
25.48(900)
77.9(2750)
77.9(2750)
Electric Consumption
kW
24
24
36
72
72
Exhaust Duct Connection
mm.
inch
203(8”)
203(8”)
203(8”)
305(12”)
305(12”)
Net Weight (approx.)
kg.
lbs
308(679)
354(780.4)
382(842.2)
558(1230.2)
702(1547.6)
Shipping Weight (approx.)
kg.
lbs
317(698.9)
364(802.5)
393(866.4)
578(1274.3)
722(1591.7)
THERMAL OIL MODEL :
Air Flow
cmm
cfm
17(600)
21.25(750)
25.48(900)
77.9(2750)
77.9(2750)
Thermal Oil Consumption
kg/hr
lb/hr
3837.6
6724.8
6724.8
20548.8
20548.8
Thermal Oil Supply Connection
NPT
1/2”
1 ½”
1 ½”
2 ½”
2 ½”
Thermal Oil Return Connection
1/2”
1 ½”
1 ½”
2 ½”
2 ½”
Exhaust Duct Connection
mm.
Inch
203(8”)
203(8”)
203(8)”
305(12”)
305(12”)
Thermal Oil Pressure
bar
psi
2-4(39-58)
2-4(39-58)
2-4(39-58)
2-4(39-58)
2-4(39-58)
Air Pressure
bar
psi
-
-
-
6-8(87-116)
6-8(87-116)
Net Weight (approx.)
kg.
lbs.
324(714.3)
460(1014.1)
460(1014.1)
N/A
865(1906.9)
Shipping Weight (approx.)
kg.
lbs.
335(738.5)
475(1047.1)
475(1047.1)
N/A
885(1951)
A. TECHNICAL SPECIFICATIONS
