Imax B6 Ultimate - Introduction

INTRODUCTION INTRODUCTION
Please read this entire operating manual completely and attentively before using this product, as it
covers a wide range of information on operating and safety. Or please do use this product in company
with a specialist!
Contact-less Key
Switch
Temperature
Probe Socket
Ventilation Fan
LCD Screen
Output
Charging
Universal
Balancing Port
Pitch=2.54mm
PC Link Socket
USB Power Supply 5V/1A
DC Input 11V~18V
Connection Diagram
03 04
Temperature
Probe Socket
