These warnings and safety notes are particularly important. Please follow the instructions for
maximum safety; otherwise the charger and the battery can be damaged or at worst it can
cause a fire.
Never leave the charger unattended when it is connected to its power supply. If any malfunction
is found, TERMINATE THE PROCESS AT ONCE and refer to the
operation manual.
Keep the charger well away from dust, damp, rain, heat, direct sunshine and vibration.
Never drop it.
The allowable input voltage is 11~18V DC
This charger and the battery should be put on a heat-resistant, noninflammable and
nonconductive surface. Never place them on a car seat, carpet or similar.
Keep all the inflammable volatile materials away from operating area.
Make sure you know the specifications of the battery to be charged or discharged to ensure it
meets the requirements of this charger. If the program is set up incorrectly, the battery and
charger may be damaged .It can cause fire or explosion due to overcharging. This warranty is
not valid for any damage or subsequent damage arising as a result of a misuse or failure to
observe the procedures outlined in this manual.
09 10
Standard Battery Parameters
3.7V/cell 3.6V/cell 3.3V/cell 1.2V/cell 1.2V/cell 2.0V/cell
4.2V/cell 4.1V/cell 3.6V/cell 1.5V/cell 1.5V/cell 2.46V/cell
3.8V/cell 3.7V/cell 3.3V/cell n/a n/a n/a
1C 1C 4C 0.4C1C-2C 1C-2C
3.0V/cell 2.5V/cell 2.0V/cell 0.85V/cell 1.0V/cell 1.75V/cell
Nominal Voltage
Min. Discharge Voltage
LiPo
Max Charge Voltage
Storage Voltage
Allowable Fast Charge
LiIon
LiFe
NiCd
MiMH
Pb
Be very careful to choose the correct voltage for different types of battery otherwise you may
cause damage to the batteries. Incorrect settings could cause the cells to fire or explode.
WARNING AND SAFETY NOTES WARNING AND SAFETY NOTES
