20
INSTALLER
USER
MAINTENANCE TECHNICIAN
Heating output.
calibrated in the central heating phase at nominal
output. It also has electronic modulation that
between the minimum heating output and the
maximum heating output depending on the
system's heating load.
N.B: the selection of the “Minimum heating
output” and “Maximum heating output”
parameters, in the presence of a central heating
request, allows switch-on of the boiler and power
supply of the modulator with current equal to
the value of the respective parameter selected.
Minimum CH output
(continuous variation)
Flashing
LED (slow)
0% Imax. (Standard setting) LED 2
7% Imax. LED 3
14% Imax. LED 4
21% Imax. LED 5
28% Imax. LED 6
35% Imax. LED 7
42% Imax. LED 8
49% Imax. LED 9
56% Imax. LED 10
63% Imax. LED 11
Maximum power
central heating
(continuous variation)
Flashing
LED (slow)
0% Imax. LED 2
11% Imax. LED 3
22% Imax. LED 4
33% Imax. LED 5
44% Imax. LED 6
55% Imax. LED 7
66% Imax. LED 8
77% Imax. LED 9
88% Imax. LED 10
100% Imax. (Standard setting) LED 11
Permanent reduction of the timer.
has electronic timing, which prevents the burner
e boiler has a standard supply of a timer
adjusted at 180 seconds.
Heating switch-on timer
(continuous variation)
Flashing
LED (slow)
30 seconds LED 2
55 seconds LED 3
80 seconds LED 4
105 seconds LED 5
130 seconds LED 6
155 seconds LED 7
180 seconds (Standard setting) LED 8
205 seconds LED 9
230 seconds LED 10
255 seconds LED 11
Central heating ramp timing.
e boiler
distributes he maximum power set in the
previous parameter.
e boiler performs an
ignition ramp of about 650 seconds to arrive
from minimum power to nominal heating power.
Central heating ramp timer
(continuous variation)
Flashing
LED (slow)
65 seconds LED 2
130 seconds LED 3
195 seconds LED 4
260 seconds LED 5
325 seconds LED 6
390 seconds LED 7
455 seconds LED 8
520 seconds LED 9
585 seconds LED 10
650 seconds (Standard setting) LED 11
Heating switch-on delay request from Room
thermostat and Comando Amico Remoto
remote control
V2
(CAR
V2
).
case of particular systems (e.g. area systems with
motorised thermostatic valves etc.) it may be
necessary to delay ignition.
Heating switch-on delay
request from Room
thermostat and CAR
V2
(continuous variation).
Flashing
LED (slow)
0 seconds (Standard setting) LED 2
57 seconds LED 3
113 seconds LED 4
170 seconds LED 5
226 seconds LED 6
283 seconds LED 7
340 seconds LED 8
396 seconds LED 9
453 seconds LED 10
510 seconds LED 11
DHW thermostat. With the “correlated”
takes place on the basis of the temperature set
using the domestic hot water adjustment selector
DHW thermostat
Flashing
LED (slow)
Correlated (Standard setting) LED 2
Fixed LED 11
Circulating pump function. Two circulating
pump operational modes can be selected in
heating phase.
In “intermittent” mode it is activated from
the room thermostat or from the Comando
Amico Remoto
V2
(CAR
V2
) remote control, in
“continuative” mode the pump always functions
when the main switch (12) is on heating mode.
Pump function
Flashing
LED (slow)
Intermittent (Standard setting) LED 2
Continuous LED 11
Town Gas G110 – Industrial gas.
of this function is used to adjust the boiler in
Town Gas G110 - Industrial Flashing
LED (slow)
LED 2
On LED 11
MAX POWER CENTRAL HEATING
(connuous variaon)
FLASHING LED (SLOW)
0% Imax.
13.4
LED 2
11% Imax.
15.7
LED 3
22% Imax.
18.1
LED 4
33% Imax.
20.5
LED 5
44% Imax.
22.9
LED 6
55% Imax.
25.3
LED 7
66% Imax.
27.6
LED 8
77% Imax.
30.0
LED 9
88% Imax.
32.4
LED 10
100% Imax. (Standard seng)
35.0
LED 11
