1.2 DESCRIPTION OF THE PRODUCT
is kit consists of an electrical box with a P.C.B. inside,
which can:
1. Check zone actuators, such as circulators or zone valves
(for 3 zones max);
2. Manage the mixing of the zones (max 2 zones);
3. Communicate with the Immergas boilers set up for
digital communication (DIM BUS) or zone signal state.
e kit does NOT include:
• Zone circulators
• Zone valves
• Mixing valves
• Temperature sensors for mixing valves
• Safety thermostats for mixed systems
• No hydraulic parts for connection to the boiler and
system zones
• No internal or external room control device
1
INSTALLATION OF THE DEVICE
1.1 GENERAL WARNINGS
All Immergas products are protected with suitable transport packaging.
e material must be stored in a dry place protected from the weather.
is instruction manual provides technical information for installing the Immergas kit. As for the other issues related to kit installation
(e.g. safety at the workplace, environmental protection, accident prevention), it is necessary to comply with the provisions specied in the
regulations in force and with the principles of good practice.
Improper installation or assembly of the Immergas appliance and/or components, accessories, kits and devices can cause unexpected problems
for people, animals and objects. Read the instructions provided with the product carefully to ensure proper installation.
Installation and maintenance must be performed in compliance with the regulations in force, according to the manufacturer's instructions
and by professionally qualied sta, meaning sta with specic technical skills in the plant sector, as envisioned by the law.
e kit can be secured to the wall with the plugs supplied with it (Fig. 2)
No. Description Q.ty
1
SELF-TAPPING SCREW TC ISO 7049 ST3.9X25 C H A3J
4
2 PLUGS MOPLEN 5X25 4
STD.009285/001
